Specifications

• Type
• EL-dB7-1.1 / EL-dB7-1.1-S
• System
• 2-way
• RMS power
• 150 Watt
• Program power
• 300 Watt
• Frequency range
• 29 Hz – 30 kHz
• Nominal impedance
• 4 Ohm
• Efficiency 2.83V/1m
• 88 dB
• Maximum SPL
• 110 dB
• Drivers

• High frequency
• 1x 1″ True Beryllium tweeter
• Mid & low frequency – Standard version
• 2x 7″ Kharma Composite driver
• Mid & low frequency – Signature version
• 2x 7″ Kharma Omega-7 driver

Dimensions

• Height
• 1011 mm / 39.80 inch
• Width
• 358 mm / 14.09 inch
• Depth
• 586 mm / 22.95 inch
