15.600€
Specs
| Rated output | Unbalanced:4W + 4W (8Ω), 2W + 2W (16Ω), 1W + 1W (32Ω), 53mW + 53mW (600Ω) Balanced:8W + 8W (16Ω), 4W + 4W (32Ω) ,213W + 213W (600Ω) |
| Instantaneous max. output | Unbalanced:5W + 5W (8Ω) Balanced:20W + 20W (8Ω) |
| Input sensitivity/ input impedance | Unbalanced:1.0V / 14kΩ Balanced:2.0V / 28kΩ |
| Frequency response | 20Hz to 20kHz (+0, -0.1dB) 10Hz to 175kHz (+0, -3.0dB) |
| Total harmonic distortion | Unbalanced:0.0025% (1kHz) Balanced:0.0015% (1kHz) |
| S/N ratio (IHF-A) | Unbalanced:117dB Balanced:119dB |
| Power transformer | OI type x 2 (L/R independent) + EI type (Peripheral circuitry) |
| Insulator feet | Cast iron density gradient x 4 |
| Power supply | 230V~(50Hz) / 115V~(60Hz) |
| Power consumption | 67W, 47W (under no signal) |
| External dimensions | 446(W) x 136(H) x 401(D) mm front side knob of 14mm and rear side terminal of 8mm included in depth |
| Net weight | 19.7kg (main unit) |
| Accessories | Power cable |
