Luxman E-07 Phono Amplifier

Luxman E-07 Phono Amplifier

ÖZELLİKLER

Luxman

7.800€



Power supply 230V~(50Hz) / 115V~(

Circuit configuration Non-feedback type phono equalizer
(RIAA, first stage four parallel FET, unbalanced configuration)
MC step-up transformer Super permalloy core x 4
(L/R channel, L/H impedance independent) : 0.3mV / 100Ω
Input sensitivity MM 3.2mV, MC-H 0.37mV, MC-L 0.12mV
Rated output /
output impedance		 250mV / Unbalanced 300Ω, Balanced 600Ω
Load capacity MM 0 / 100 / 200 / 320pF
Gain MM 38dB, MC-H 57dB, MC-L 66dB
Maximum input MM 120mV, MC-H 15mV, MC-L 5mV
RIAA response MM 20Hz to 20kHz (±0.1dB), MC 20Hz to 20kHz(±0.3dB)
Total harmonic distortion 0.003%



S/N ratio (IHF-A) MM 88dB, MC-H 81dB, MC-L 78dB
Channel separation 80dB or more
Power transformer OI type x 3 (L/R independent + Peripheral circuit)
Insulator feet Density gradient

60Hz)
Power consumption 13W
External dimensions 440(W) x 92(H) x 407(D) mm
front side knob of 14mm and rear side terminal
of 37mm included in depth
Net weight 13.2kg (main unit)
Accessories Power cable
