POWER SUPPLY

Nominal line voltage: 110 V or 220 V

Input voltage range: +/- 10 %

2x 350 VA Toroidal Power Transformer

Capacitor bank: 46’000 μF

OUTPUT POWER
Maximum power (IEC 62368-1):
· 2 x 250 Wrms on 8 Ω / 1 % THD
· 2 x 320 Wrms on 4 Ω / 1 % THD

RATED POWER CONSUMPTION

IEC 62368-1, 1/8 Output Power at 8 Ω: 275 W

REAR PANEL
2 x output binding posts (left & right)
1 x On/Off power switch key
1 x Voltage input selector
RS232 Command connector
1 x USB device: Audio Class 2.0 (no driver required
on Mac OS X as of v.10.6.4 nor on Linux,
driver required only for Windows, contact your
Goldmund representative):
· Sample rate up to 384 kHz/Bit depth up to 32
· DSD64, DSD128 over PCM capabilities
1 x Toslink Optical
1 x Digital S/PDIF coaxial RCA 75 Ohms
5 x Analog RCA (left & right)

INPUT
Max level before clipping, Analogue input: 1 Vrms
Max level before clipping, Digital input: -6 dBFS

OUTPUT
Max level before clipping, 1 % THD, unloaded:
170 Vpp
